profile 45x90 heavy closed Code: BPRDD0001147 Serie: 45 Area: 11,405 mm2 Bar length: 6040 mm Materiale: Alloy EN AW 6060 Modulo di resistenza: 11,077 Wx/cm3 – 21,483 Wy/cm3 Moment of inertia: 24,925 Jx/cm4 – 96,674 Jy/cm4 Weight: 3,091 kg/ml Cad 2D Cad 3D Fixing Plate Serie 30-45 seat for nut Profile 60 fixing plate with Profile 30
